Steam boilers
Tailored solutions for sophisticated steam production: The steam boilers outputs range from 175 to 55,000 kilograms per hour are available for a wide range of applications. Product dimensions and equipment levels are tailored to the customer's individual needs, and a wide range of options and variants are available. The result: maximum energy efficiency, excellent conservation of resources and outstanding availability. The intelligent control technology from Bosch ensures convenient, fully-automatic industrial heating system.
-
UNIVERSAL Steam Boiler U-ND, U-HD
- Heat transfer medium Low-pressure saturated steam High-pressure saturated steam
- Design Flame tube/smoke tube technology Flame tube/smoke tube technology
- Output 175 to 3,200 kg/h 175 to 1,250 kg/h
- Safety pressure up to 0.5 bar up to 16 bar
- Max temperature to 110 °C to 204 °C
- Fuel Gas, Oil
- The U-HD and U-ND industrial steam boilers are a perfect solution for smaller manufacturing businesses and processing companies as well as the service industry.
-
UNIVERSAL Steam Boiler U-MB
- Heat transfer medium High-pressure saturated steam
- Design Three-pass flame tube/smoke tube technology
- Output 200 to 2,000 kg/h
- Safety pressure up to 16 bar
- Max. flow temperature 204 °C
- Fuel Oil, Gas
- The common areas of application of the U-MB steam boiler are the food and drinks industries, hospitals and cleaning companies.
-
UNIVERSAL Steam Boiler UL-S, UL-SX
- Heat transfer medium High-pressure saturated steam High-pressure superheated steam
- Design Three-pass single-flame tube/smoke tube technology Three-pass single-flame tube/smoke tube technology
- Output 1,250 to 28,000 kg/h 2,600 to 28,000 kg/h
- Safety pressure up to 30 bar up to 30 bar
- Max. flow temperature 235 °C 300 °C
- Fuel Oil, gas
- UNIVERSAL UL-S steam boilers are mainly used in the processing industry, in the commercial sector or in communal blocks.
-
UNIVERSAL Steam Boiler ZFR, ZFR-X
- Heat transfer medium High-pressure saturated steam High-pressure superheated steam
- Design Three-pass double-flame tube/smoke tube technology Three-pass double-flame tube/smoke tube technology
- Output 18,000 to 55,000 kg/h 18,000 to 55,000 kg/h
- Safety pressure up to 30 bar up to 30 bar
- Max. flow temperature to 235 °C to 300 °C
- Fuel Gas, Oil
- The ZFR series is ideally suited for a range of process driven industries with high pressure requirements.
